Model NO. | CP-G2 |
Camera | |
Sensor Type | 1/3" CMOS |
Shutter | Adaptive Shutter |
Lens | 3.6mm@F1.6, Diagonal Field of View: 91°, Horizontal: 77°, Vertical: 41° |
Pan/Tilt Rotation Angles | Horizontal 0°-350°, Vertical 0°-90° |
Lens Interface Type | M12 |
Day/Night Mode | ICR Infrared Filter |
Digital Noise Reduction | 3D Digital Noise Reduction |
Wide Dynamic Range | / |
Interfaces/Buttons | |
Storage Interface | Micro SD Card (up to 512GB) |
Power Interface | Type-C Interface |
Reset Button | 1 |
Power Switch | 1 |
Compression Standards | |
Video Compression Standards | H.265/H.264 |
Video Bitrate | Adaptive Bitrate |
Audio Bitrate | Adaptive Bitrate |
Video | |
Maximum Video Size | Maximum 1920x1080, supports dual stream |
Frame Rate | Maximum 15fps |
Image Flip | Support |
Backlight Compensation | Support |
Software Features | |
Working Mode | Smart Mode/Constant Power Mode/AOV Mode/Power-Saving Mode/Sleep Mode |
Smart Alarm | Person/Vehicle Detection |
Two-Way Audio | Support |
Auto Tracking | Support |
Gun-ball Linkage | / |
Pan/Tilt Presets | Support, up to 6 presets |
4G Parameters | |
Network Standards | LTE-TDD(CN):B34/B38/B39/B40/B41 LTE-FDD(CN):B1/B3/B5/B8 LTE-FDD(EU): B1/B3/B5/B7/B8/B20/B28 LTE-FDD(NAA):B2/B4/B5/B12/B13/B66/B71 |
LTE Category | Cat1 |
Built-in SIM Card | Not Built-in |
External Removable SIM Card | Support |
Solar Panel | |
Output Power | 8W |
Standard Output Voltage | 5V |
Maximum Output Current | 1.52A |
Operating Temperature | -20~60℃ |
Dimensions | 264×172mm |
Lithium Battery | |
Battery Capacity | 8800mAh |
General Specifications | |
Operating Temperature and Humidity | -10℃~45℃, Humidity less than 95% (non-condensing) |
Power Supply | Type-C Charging Port DC 5V/2A (user needs to provide) |
Infrared Illumination Distance | 20m |
Dimensions (mm) | 154×117×168mm |
Weight | 790g (bare unit) |
