| Model NO. | CQ-G4 |
| Camera | |
| Sensor Type | 1/3" CMOS |
| Shutter | Adaptive Shutter |
| Lens | 3.6mm@F1.6, Diagonal Field of View: 90°, Horizontal: 76°, Vertical: 40° |
| Pan/Tilt Rotation Angles | Horizontal 0°-350°, Vertical 0°-90° |
| Lens Interface Type | M12 |
| Day/Night Mode | ICR Infrared Filter |
| Digital Noise Reduction | 3D Digital Noise Reduction |
| Wide Dynamic Range | / |
| Interfaces/Buttons | |
| Storage Interface | Micro SD Card (up to 512GB) |
| Power Interface | Type-C Interface |
| Reset Button | 1 |
| Call Button | 1 |
| Compression Standards | |
| Video Compression Standards | H.265/H.264 |
| Video Bitrate | Adaptive Bitrate |
| Audio Bitrate | Adaptive Bitrate |
| Image | |
| Maximum Image Size | Maximum 2560x1440, supports dual stream |
| Frame Rate | Maximum 15fps |
| Image Flip | Support |
| Backlight Compensation | Support |
| Software Features | |
| Smart Alarm | Smart Mode/Constant Power Mode/AOV Mode/Power-Saving Mode/Sleep Mode |
| Two-Way Audio | Person/Vehicle Detection |
| Voice Call | Support |
| Auto Tracking | Support |
| Gun-ball Linkage | / |
| Pan/Tilt Presets | Support, up to 6 presets |
| 4G Parameters | |
| Network Standards | LTE-TDD:B34/B38/B39/B40/B41 LTE-FDD:B1/B3/B5/B8 |
| LTE Category | Cat1 |
| Built-in SIM Card | Built-in Unicom SIM Card |
| External Removable SIM Card | Support |
| Solar Panel | |
| Output Power | 8W |
| Standard Output Voltage | 5V |
| Maximum Output Current | 1.52A |
| Operating Temperature | -20~60℃ |
| Dimensions | 264×172mm |
| Lithium Battery | |
| Battery Capacity | 8800mAh |
| General Specifications | |
| Operating Temperature and Humidity | -10℃~45℃, Humidity less than 95% (non-condensing) |
| Power Supply | Type-C Charging Port DC 5V/2A (user needs to provide) |
| Infrared Illumination Distance | 20m |
| Dimensions (mm) | 151×114×134mm |
| Weight | 585g (bare unit) |
