| Model NO. | CDK1-W1X5-B |
| Camera | |
| Sensor Type | 1/2.9" CMOS |
| Shutter | Adaptive Shutter |
| Lens | 3.6mm@F1.0, Diagonal Field of View: 90°, Horizontal: 76°, Vertical: 40° |
| Pan/Tilt Rotation Angles | Horizontal 0°-350°, Vertical 0°-90° |
| Lens Interface Type | M12 |
| Day/Night Mode | Full-color night vision |
| Digital Noise Reduction | 3D Digital Noise Reduction |
| Wide Dynamic Range | / |
| Interfaces/Buttons | |
| Storage Interface | Micro SD Card (up to 512GB) |
| Power Interface | Type-C Interface |
| Reset Button | 1 Pcs |
| Power Switch | 1 Pcs |
| Compression Standards | |
| Video Compression Standards | H.265/H.264 |
| Video Bitrate | Adaptive Bitrate |
| Audio Bitrate | Adaptive Bitrate |
| Video | |
| Maximum Video Size | Maximum 2880x1620, supports dual stream |
| Frame Rate | Maximum 15fps |
| Image Flip | Support |
| Backlight Compensation | Support |
| Software Features | |
| Smart Alarm | Person/Vehicle Detection |
| Sound Alarm | Support |
| Two-Way Audio | Support |
| Wireless Parameters | |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax，WiFi 6，Support 2.4G/5G dual-band |
| Bluetooth | Bluetooth v5.4 |
| General Specifications | |
| Operating Temperature and Humidity | -10℃~55℃, Humidity less than 95% (non-condensing) |
| Power Supply | Type-C Charging Port DC 5V/1A |
| Dimensions (mm) | 55×67×36mm |
| Weight | 60g (bare unit) |
